The UIYDI2531A800T1000 is a high-performance Drop in Isolator specifically designed for modern communication systems and radio frequency (RF) applications. This product offers exceptional electrical performance across a wide frequency range of 800 MHz to 1000 MHz, ensuring the stability and efficiency of signal transmission. With its outstanding isolation capability and low insertion loss, the UIYDI2531A800T1000 has become a crucial component in numerous wireless communication systems.
Design Features:
High Isolation: The product provides up to 19 dB of isolation, effectively preventing signal reflection and interference, and ensuring the purity of unidirectional signal transmission.
Low Insertion Loss: With only 0.4 dB of insertion loss, it minimizes signal attenuation during transmission, enhancing overall system efficiency.
Broadband Coverage: Covering a frequency range of 800 MHz to 1000 MHz, it is suitable for various communication standards and frequency bands, offering flexible adaptation to different application scenarios.
Excellent VSWR: A VSWR of 1.25 dB ensures good signal matching on the transmission line, reducing reflection loss.
High Power Handling Capability: Supporting up to 200W of forward power and 150W of reverse power, it is suitable for high-power communication systems.
TAB Interface: Using a TAB connector type, it facilitates easy installation and connection, improving system integration.
Wide Operating Temperature Range: With an operating temperature range of -40°C to +85°C, it ensures stable operation in various extreme environments.
Applications:
Wireless Communication Base Stations: Enhances the reliability and stability of base station signal transmission, reducing signal interference.
Satellite Communication Systems: Ensures unidirectional signal transmission and high-quality reception in satellite ground stations and antenna systems.
Radar Systems: Improves the clarity of radar signals, reduces clutter interference, and enhances target detection capabilities.
Broadcasting and Television Transmission: Ensures efficient transmission of broadcasting and television signals, enhancing the viewer’s reception experience.
Radio Test Equipment: Acts as a key component for signal isolation and control in radio test experiments.
Specification Information:
Model: UIYDI2531A800T1000
Frequency Range: 800 ~ 1000 MHz
Insertion Loss: 0.4 dB
Isolation: 19 dB
VSWR: 1.25 dB
Forward Power: 200W
Reverse Power: 150W
Connector Type: TAB
Operating Temperature: -40°C to +85°C
Manufacturer: UIY Inc.
The UIYDI2531A800T1000, with its exceptional performance and broad application adaptability, is an ideal choice for enhancing communication system performance. Whether you are building new communication infrastructure or optimizing existing systems, this stripline isolator provides you with a stable and efficient solution.
For more information about other related products or custom requirements for coaxial isolators, please feel free to contact us.
